Moisture Analyzer, MB90
Details
The Ohaus MB90 Moisture Analyzer combines speed and precision in one moisture analyzer. You can test more samples in less time. The precisely controlled halogen heating dries samples quickly and ensures uniform heating to yield fast, precise and repeatable results of 0.01% readability. It is designed with effortless maintenance in mind, featuring a removable pan holder and heating components that make cleaning quick and easy with no tools. The icon-based menu navigation on the touchscreen display makes the operation intuitive. You can perform routine sample testing in three easy steps.
Applications: Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display: 4.3" TFT color touchscreen display
Operation: Power cord (included)
Communication: RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction: Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features: Three shut-off criteria (manual, timed or auto), two drying profiles (standard and fast), storage up to two methods, user guide, 40°C to 200°C heating temperature range (1°C increments), 14 operational languages
Specifications:
Maximum Capacity: 90 g
Readability Moisture Content: 1 mg/0.01%
Pan Size: 3.5 in (90 mm)
Heater Type: Halogen Lamp
Communication: USB host x 2; USB device; RS232
Dimensions (H x L x W): 7.09 x 13.98 x 8.31 in (180 x 355 x 211 mm)
Display: Full-Color 4.3 in Touchscreen WQVGA
Heating Profiles: Standard; Fast
In-use cover: Included
Moisture Range: 0 % – 100 %
Net Weight: 11.53 lb (5.23 kg)
Operating Range (Temp.): 10 °C – 40 °C
Power: 115 v, 60 Hz
Sample Size: 0.5 g – 90 g
Shut-Off Criteria: Manual; Timed; Auto
Tare Range: 0g–225g
Temperature Range: 40 °C – 200 °C
Test Library: 2
Units of Measurement: Gram; %MC; %RG; %DC
Working Environment: 50°F – 104°F, 85%RH, non-condensing (10°C – 40°C, 85%RH, non-condensing)
Product Documents:
QuickStart Guide
Product Flyer
Product Manual
Service Manual
Applications: Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display: 4.3" TFT color touchscreen display
Operation: Power cord (included)
Communication: RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction: Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features: Three shut-off criteria (manual, timed or auto), two drying profiles (standard and fast), storage up to two methods, user guide, 40°C to 200°C heating temperature range (1°C increments), 14 operational languages
Specifications:
Maximum Capacity: 90 g
Readability Moisture Content: 1 mg/0.01%
Pan Size: 3.5 in (90 mm)
Heater Type: Halogen Lamp
Communication: USB host x 2; USB device; RS232
Dimensions (H x L x W): 7.09 x 13.98 x 8.31 in (180 x 355 x 211 mm)
Display: Full-Color 4.3 in Touchscreen WQVGA
Heating Profiles: Standard; Fast
In-use cover: Included
Moisture Range: 0 % – 100 %
Net Weight: 11.53 lb (5.23 kg)
Operating Range (Temp.): 10 °C – 40 °C
Power: 115 v, 60 Hz
Sample Size: 0.5 g – 90 g
Shut-Off Criteria: Manual; Timed; Auto
Tare Range: 0g–225g
Temperature Range: 40 °C – 200 °C
Test Library: 2
Units of Measurement: Gram; %MC; %RG; %DC
Working Environment: 50°F – 104°F, 85%RH, non-condensing (10°C – 40°C, 85%RH, non-condensing)
Product Documents:
QuickStart Guide
Product Flyer
Product Manual
Service Manual
