AFB Staining Kinyoun Kit

Staining of bacteria from cultures or patient specimens suspected to contain Mycobacteria tuberculosis can be easily achieved using one of two methods: (1) hot method or (2) cold method. The traditional Ziehl Neelsen Method employs the use of heat, for which it is known as the hot method. Ziehl Neelsen staining method uses “heated” Carbol-fuchsin solution as a primary stain, followed by a decolorizer solution and a methylene blue solution as a counterstain. Whereas the Kinyoun Method provides a cold method alternative for staining without the need for heat with brilliant green or methylene blue counterstain option.

Acid-fast organisms are stained red, while non-acid-fast organisms and the background are stained green or blue. A major characteristic of mycobacteria is that they are “acid-fast” and once stained with aniline dye, basic fuchsin, they are difficult to decolorize, thus retaining the red color even when exposed to an acid alcohol rinse. Whether you’re testing surgical specimens, respiratory or sputum specimens, the two counterstains brilliant green and methylene blue will provide easy identification to the non-acid fast organisms.

Procedure
1. Fix the slide.
2. Place fixed smear on a staining rack.
3. Stain slide using preferred hot or cold method:
Ziehl Neelsen (hot method): Flood slide with Ziehl Neelsen solution and heat: 3 minutes (avoid boiling)
Carbol Fuchsin (cold method): Flood slide with Carbol Fuchsin solution: 5 minutes
4. Rinse gently with DI water.
5. Remove excess stain using the Decolorizer solution until the rinses appear clear.
6. Rinse gently with DI water.
7. Flood slide with Counterstain (Methylene Blue or Brilliant Green) for 30 seconds.
8. Rinse gently with DI water until clear.
9. Examine dry under high magnification and verify under oil immersion.

Results
The “acid fast” organisms will appear red
Non-“acid fast” organisms will appear blue or green

Features:
- Kit includes Carbol Fuchsin - Kinyoun, Decolorizer, and Methylene Blue counter stain
- 8 oz. bottles with spout caps
