Moisture Analyzer, MB120
Details
The Ohaus MB120 Moisture Analyzer makes moisture analysis simple and powerful. The temperature guide analyzes a sample and determines the optimal drying temperature. You can store up to 100 drying methods for easy recall an up to 1000 total results for statistical analysis. The precisely controlled halogen heating dries samples uniformly, producing repeatable results of 0.01% readability. Four drying profiles, predefined and user defined shut-ogg criteria help to perform customized sample tests. The MB120 features a removable pan handler and sample chamber for easy cleaning. The guided instructions on the touchscreen display makes this unit easy to use.
Applications: Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display: 4.3" TFT color touchscreen display
Operation: Power cord (included)
Communication: RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction: Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features: Three shut-off criteria (manual, timed or auto), two drying profiles (standard and fast), storage up to two methods, user guide, 40°C to 200°C heating temperature range (1°C increments), 14 operational languages
Specifications:
Maximum Capacity: 120 g
Readability Moisture Content: 1 mg/0.01%
Pan Size: 3.5 in (90 mm)
Heater Type: Halogen Lamp
Communication: USB host x 2; USB device; RS232
Dimensions (H x L x W): 7.09 x 13.98 x 8.31 in (180 x 355 x 211 mm)
Display: Full-Color 4.3 in Touchscreen WQVGA
Heating Profiles: Standard; Ramp; Step; Fast
In-use cover: Included
Moisture Range: 0 % – 100 %
Net Weight: 11.53 lb (5.23 kg)
Operating Range (Temp.): 10 °C – 40 °C
Power: 115 v, 60 Hz
Sample Size: 0.5 g – 120 g
Shut-Off Criteria: Manual; Timed; Automatic - Preset Weight Loss/Time; Custom - User Set Weight Loss/Time; Custom-User Set Moisture% Loss/Time
Temperature Range: 40 °C – 230 °C
Test Library: 100
Units of Measurement: Gram; %MC; %RG; %DC
Working Environment: 50°F – 104°F, 85%RH, non-condensing (10°C – 40°C, 85%RH, non-condensing)
Product Documents:
QuickStart Guide
Product Flyer
Product Manual
Service Manual
Applications: Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing
Display: 4.3" TFT color touchscreen display
Operation: Power cord (included)
Communication: RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction: Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features: Three shut-off criteria (manual, timed or auto), two drying profiles (standard and fast), storage up to two methods, user guide, 40°C to 200°C heating temperature range (1°C increments), 14 operational languages
Specifications:
Maximum Capacity: 120 g
Readability Moisture Content: 1 mg/0.01%
Pan Size: 3.5 in (90 mm)
Heater Type: Halogen Lamp
Communication: USB host x 2; USB device; RS232
Dimensions (H x L x W): 7.09 x 13.98 x 8.31 in (180 x 355 x 211 mm)
Display: Full-Color 4.3 in Touchscreen WQVGA
Heating Profiles: Standard; Ramp; Step; Fast
In-use cover: Included
Moisture Range: 0 % – 100 %
Net Weight: 11.53 lb (5.23 kg)
Operating Range (Temp.): 10 °C – 40 °C
Power: 115 v, 60 Hz
Sample Size: 0.5 g – 120 g
Shut-Off Criteria: Manual; Timed; Automatic - Preset Weight Loss/Time; Custom - User Set Weight Loss/Time; Custom-User Set Moisture% Loss/Time
Temperature Range: 40 °C – 230 °C
Test Library: 100
Units of Measurement: Gram; %MC; %RG; %DC
Working Environment: 50°F – 104°F, 85%RH, non-condensing (10°C – 40°C, 85%RH, non-condensing)
Product Documents:
QuickStart Guide
Product Flyer
Product Manual
Service Manual
